Description
NSK 7013A5TYNSULP4 — Super-Precision Spindle Bearing
Super-Precision Spindle Bearing from NSK’s super-precision range, for grinding, milling and high-speed machine-tool spindles where running accuracy is required. Universally matchable for paired or multi-bearing arrangements. Sold per bearing — order the quantity your arrangement requires.
Specifications
- Brand: NSK
- Designation: 7013A5TYNSULP4
- Type: Super-Precision Spindle Bearing
- Bore (d): 65 mm
- Outside diameter (D): [confirm from datasheet] mm
- Width (B): [confirm from datasheet] mm
- Contact angle: 25°
- Precision class: P4 (≈ ABEC 7)
- Preload: light, universal matching
- Cage: polyamide (nylon) cage
- Sealing: Open (relubrication via spindle system)
Suffix breakdown — what you are actually buying
- 25° contact angle — higher axial stiffness than the 15° variant; suited to the fixed/locating spindle position and higher axial cutting loads.
- Polyamide (nylon) cage — low mass and quiet at speed; the standard for high-speed spindle service.
- P4 — ISO precision class (≈ ABEC 7) with restricted running tolerances for low radial and axial runout and repeatable concentricity.
- light preload, universal matching — mounts in DB/DF/DT arrangements to the designed preload when clamped.
- Full designation — supplied and verified exactly as specified: 7013A5TYNSULP4.
What this means on the spindle
- High rigidity: defined contact angle and preload hold the shaft against axial and radial cutting forces, protecting tolerance under load.
- Low runout: super-precision running accuracy keeps concentricity tight for surface finish and tool life.
- Long service life: precision raceways and controlled preload extend service intervals and reduce failures.
10+ Years FAG Bearing Specialist Support
Every order is checked by a specialist with over a decade in FAG precision bearings. Send us the full designation and we will verify every prefix and suffix — contact angle, cage, precision class, preload and sealing — so the part you receive is an exact match for your spindle, not an approximate substitute. FAG, INA (Schaeffler Group), SKF, NSK and IBC references are supplied as 100% genuine product, with documentation available on request and express cross-border shipping to the UK and EU.
