The 71988-MPA-P5 FAG is a large single row angular contact ball bearing with a machined brass cage guided by the outer ring, designed for high-precision applications requiring P5 accuracy and high axial load capacity.
-
Brand: FAG (Schaeffler)
-
Type: Angular Contact Ball Bearing Single Row
-
Bore (d): 440 mm / 17.3228 in
-
Outer Diameter (D): 600 mm / 23.622 in
-
Width (B): 74 mm / 2.9134 in
-
Weight: 56.9 kg
-
Seal: No Seal (Open)
-
Cage: MA – Brass Cage, Centered on Outer Ring
-
Precision: P5 – Higher than P6 (ISO Tolerance Class 5)
-
Contact Angle: 30 degrees
-
Pairing: No Pairing
-
Preload: No Preload
-
Lubrication: Standard
-
Radial Static Load Rating C0r: 990,000 N
-
Radial Dynamic Load Rating Cr: 500,000 N
-
Limiting Speed: 1510 n G
-
Reference Speed: 920 n ϑr
Ideal for heavy industrial machinery, turbines, and precision equipment requiring superior dimensional accuracy and reliable performance under combined loads.
