FAG HS7004-C-T-P4S-UL Super-Precision Spindle Bearing (20mm, 15°, P4, light preload)

FAG HS7004-C-T-P4S-UL — Super-Precision Spindle Bearing

Super-Precision Spindle Bearing from FAG’s super-precision range, for grinding, milling and high-speed machine-tool spindles where running accuracy is required. Universally matchable for paired or multi-bearing arrangements. Sold per bearing — order the quantity your arrangement requires.

Specifications

• Brand: FAG
• Designation: HS7004-C-T-P4S-UL
• Type: Super-Precision Spindle Bearing
• Bore (d): 20 mm
• Outside diameter (D): [confirm from datasheet] mm
• Width (B): [confirm from datasheet] mm
• Contact angle: 15°
• Precision class: P4 (≈ ABEC 7) — restricted spindle tolerances
• Preload: light, universal matching
• Cage: machined phenolic-resin cage
• Sealing: Open (relubrication via spindle system)

Suffix breakdown — what you are actually buying

• 15° contact angle — favours higher speed and lower heat; the common choice for the floating spindle position.
• Machined phenolic-resin cage — low mass and quiet at speed; the standard for high-speed spindle service.
• P4 — ISO precision class (≈ ABEC 7) with restricted running tolerances for low radial and axial runout and repeatable concentricity.
• light preload, universal matching — mounts in DB/DF/DT arrangements to the designed preload when clamped.
• Full designation — supplied and verified exactly as specified: HS7004-C-T-P4S-UL.

What this means on the spindle

• High rigidity: defined contact angle and preload hold the shaft against axial and radial cutting forces, protecting tolerance under load.
• Low runout: super-precision running accuracy keeps concentricity tight for surface finish and tool life.
• Long service life: precision raceways and controlled preload extend service intervals and reduce failures.

10+ Years FAG Bearing Specialist Support

Every order is checked by a specialist with over a decade in FAG precision bearings. Send us the full designation and we will verify every prefix and suffix — contact angle, cage, precision class, preload and sealing — so the part you receive is an exact match for your spindle, not an approximate substitute. FAG, INA (Schaeffler Group), SKF, NSK and IBC references are supplied as 100% genuine product, with documentation available on request and express cross-border shipping to the UK and EU.
