SGU 7000C High-Precision Angular Contact Ball Bearing
The SGU 7000C is a single-row angular contact ball bearing designed for applications requiring combined radial and axial loads. With a 15° contact angle, it delivers excellent high-speed performance and rigidity.
Specifications
-
Designation: 7000C
-
Bore Diameter (d): 10 mm
-
Outer Diameter (D): 26 mm
-
Width (B): 8 mm
-
Contact Angle: 15°
-
Basic Dynamic Load Rating (Cr): 4.58 kN
-
Basic Static Load Rating (Cor): 1.97 kN
-
Limiting Speed (grease): 35,000 rpm
-
Limiting Speed (oil): 50,000 rpm
Features
- High-speed capability suitable for machine tool spindles
- 15° contact angle for balanced radial and axial load capacity
- Precision manufactured to ISO standards
- Available in C (15°) and AC (25°) contact angle variants
Applications
Machine tool spindles, pumps, compressors, electric motors, and other high-speed rotating equipment.
