SGU 7001C High-Precision Angular Contact Ball Bearing
Single-row angular contact ball bearing with 15° contact angle for high-speed applications.
Specifications
-
Designation: 7001C
-
Bore Diameter (d): 12 mm
-
Outer Diameter (D): 28 mm
-
Width (B): 8 mm
-
Contact Angle: 15°
-
Basic Dynamic Load Rating (Cr): 5.1 kN
-
Basic Static Load Rating (Cor): 2.38 kN
-
Limiting Speed (grease): 32,000 rpm
-
Limiting Speed (oil): 45,000 rpm
Applications
Machine tool spindles, pumps, electric motors, and high-speed rotating equipment.
Contact us for pricing and availability.
