SGU 7002C High-Precision Angular Contact Ball Bearing
Single-row angular contact ball bearing with 15° contact angle for high-speed applications.
Specifications
-
Designation: 7002C
-
Bore Diameter (d): 15 mm
-
Outer Diameter (D): 32 mm
-
Width (B): 9 mm
-
Contact Angle: 15°
-
Basic Dynamic Load Rating (Cr): 5.4 kN
-
Basic Static Load Rating (Cor): 2.75 kN
-
Limiting Speed (grease): 28,000 rpm
-
Limiting Speed (oil): 40,000 rpm
Applications
Machine tool spindles, pumps, electric motors, and high-speed rotating equipment.
Contact us for pricing and availability.
